IGBT MODULE SKKE162/16

Product Description

The SKKE162/16 is a Semikron high-power rectifier diode module, not an IGBT module. It is used for AC to DC conversion in heavy industrial power systems.

Key Features

• High-power rectifier diode module (single diode type inside module structure)
• Designed for industrial AC → DC rectification
• Very high voltage blocking capability (1600V class)
• High current handling for heavy loads
• Low forward voltage drop for efficient operation
• Screw-mounted module for heatsink installation
• High surge current capability for motor and drive systems
• Rugged SEMIPACK industrial housing

Specifications

• Product Type: Rectifier Diode Power Module
• Model: SKKE162/16
• Manufacturer: Semikron (Semikron Danfoss)
• Repetitive Peak Reverse Voltage (VRRM): 1600 V
• Average Forward Current (IFAV): 160–195 A (depending on cooling conditions)
• Surge Forward Current (IFSM): up to ~5000 A (10 ms pulse)
• Package Type: SEMIPACK 2 industrial module
• Mounting: Screw-mounted on heatsink
• Operating Temperature: approx. -40°C to +135°C (typical class range)
• Isolation: High-voltage insulated baseplate (~3000V class)
